| PartNumber | CT024TN02 V.6 |
| Brand | Innolux |
| Size | 2.4 |
| Application | Mobile Phone |
| Resolution | 240×320 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 300:1 |
| Colors | 65K |
| Backlight | WLED |
| Interface | |
| Model | CT024TN02 V.6 |
| Diagonal Size | 2.4 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 240(RGB)×320 [QVGA] 166PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 36.72(H)×48.96(V) mm |
| Outline Dim. | - |
| Luminance | - |
| Contrast Ratio | 300:1 (Typ.) (TM) |
| View Direction | 12 o'clock |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 45/45/50/20 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 65K 60% NTSC |
| Light Source | WLED |
| Weight | - |
| Designed For | Mobile Phone |
| Frame Rate | - |
| Touch Panel | 4-wire Resistive Touch |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
