| PartNumber | DBT070CTV50R9 |
| Brand | No Brand |
| Size | 7.0 |
| Application | Industrial Outdoor H |
| Resolution | 800×480 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 500:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Diagonal Size | 7.0 inch |
| Pixel Format | 800(RGB)×480 [WVGA] 134PPI |
| Active Area | 154.08(H)×85.92(V) mm |
| Bezel Area | 157(H)×89.5(V) mm |
| Luminance | 1000 cd/m² (Typ.) |
| View Direction | - |
| Viewing Angle | 70/70/50/70 (Typ.)(CR≥10) |
| Support Color | 16.7M |
| Weight | TBD |
| Frame Rate | 60Hz |
| Model | DBT070CTV50R9 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 165(H)×100(V) mm |
| Treatment | Antiglare |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Response Time | 10/15 (Typ.)(Tr/Td) |
| Operating Mode | TN, Normally White, Transmissive |
| Light Source | WLED , 20K hours , W/O Driver |
| Designed For | Industrial Outdoor High Brightness |
| Touch Panel | Without |
| AT070TN83 | Innolux | 7.0 | 800×480 |
| AT070TN83 V.1 | Innolux | 7.0 | 800×480 |
| AT070TN94 | Innolux | 7.0 | 800×480 |
| C070VW02 V1 | AUO | 7.0 | 800×480 |
| G070VVN01.0 | AUO | 7.0 | 800×480 |
| LMS700KF07 | Samsung | 7.0 | 800×480 |
| LQ070T1LG01 | SHARP | 7.0 | 800×480 |
| LQ070Y5DG30 | SHARP | 7.0 | 800×480 |
| PM070WL3 | E Ink | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
