| PartNumber | DLC0500AIG-2 |
| Brand | Other |
| Size | 5.0 |
| Application | VDP |
| Resolution | 640(RGB)×480 , VGA |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | TTL |
| Panel Brand | DLC |
| Panel Model | DLC0500AIG-2 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 5.0 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 101.568×76.176 mm |
| Outline | 117.65×88.43×6 mm |
| Surface | Antiglare |
| Contrast Ratio | 500:1 (Typ.) |
| Display Colors | 262K (6-bit), CIE193140% |
| Response Time | 10/10 (Typ.)(Tr/Td) |
| Viewing Angle | 60/60/60/45 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 3S6PWLEDWithout Driver |
| Signal Interface | Parallel RGB (1 ch, 6-bit), 40 pins |
| Input Voltage | 3.3V (Typ.)(VCC) |
