| PartNumber | DV460FHM-NV2 |
| Brand | BOE |
| Size | 46 |
| Application | Video Wall |
| Resolution | 1920×1080 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 1200:1 |
| Colors | 16.7M |
| Backlight | WLED , 50K hours , With LED Driver |
| Interface | LVDS |
| Manufacturer | BOE |
| Screen Size | 46 inch |
| Pixel Number | 1920(RGB)×1080 (FHD) 47PPI |
| Active Area(mm) | 1018.08 × 572.67 (H×V) |
| Bezel Area(mm) | - |
| Luminance | 500 cd/m² (Typ.) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 16.7M 95% sRGB |
| Splicing Seam | 0.9 mm (active to active seam) |
| Refresh Rate | 60Hz |
| Signal Type | LVDS (2 ch, 8-bit) , 51 pins Connector |
| Voltage Supply | 12.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| Model Name | DV460FHM-NV2 |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 1018.96 × 573.55 × 58.3 (H×V×D) |
| Treatment | Antiglare (Haze 25%), Hard coating (2H) |
| Contrast Ratio | 1200 : 1 (Typ.) (TM) |
| Response | 8 (Typ.)(G to G) ms |
| Work Mode | ADS, Normally Black, Transmissive |
| Used for | Video Wall |
| Touchscreen | Without |
| HV460WUC-200 | BOE | 46 | 1920×1080 |
| LSC460HW01 | Samsung | 46 | 1920×1080 |
| LTA460HM03 | Samsung | 46 | 1920×1080 |
| LTA460HM06 | Samsung | 46 | 1920×1080 |
| LTA460HQ23 | Samsung | 46 | 1920×1080 |
| LTF460HF08 | Samsung | 46 | 1920×1080 |
| T460HW03 VF | AUO | 46 | 1920×1080 |
| T460HW04 V0 | AUO | 46 | 1920×1080 |
| T460HW08 V0 | AUO | 46 | 1920×1080 |
| V460H1-LS2 | Innolux | 46 | 1920×1080 |
