| PartNumber | E295FCA62.A |
| Brand | EDO |
| Size | 3.0 |
| Application | HMD VR AR |
| Resolution | 1080×1200 |
| Composition | AM-OLED, OLED |
| Brightness | |
| CR | 10000:1 |
| Colors | 16.7M |
| Backlight | self |
| Interface | MIPI |
| Model | E295FCA62.A |
| Diagonal Size | 3.0 inch |
| Type | AM-OLED, OLED |
| Pixel Format | 1080(RGB)×1200 446PPI |
| Configuration | Sub-Pixel Rendering |
| Active Area | 50.11(H)×55.68(V) mm |
| Outline Dim. | 52.91(H)×62.58(V) ×0.75(D) mm |
| Luminance | 300 cd/m² (Typ.) |
| Contrast Ratio | 10000:1 (Min.) (TM) |
| View Direction | Symmetry |
| Response Time | 2 (Typ.)(Tr+Tf) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥200) |
| Operating Mode | - |
| Support Color | 16.7M 109% NTSC |
| Light Source | self |
| Weight | 4.80±0.40g |
| Designed For | HMD VR AR |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| D-IC Detail | COG Built-in RM67295 |
| Interface Type | MIPI (4 data lanes) , 39 pins FPC |
| Power Supply | 1.8/3.3/6.4/4.6/-2.5V (Typ.)(VDDI/VCI/VSP/ELVDD/ELVSS) |
| Environment | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -55 ~ 125 °C |
