| PartNumber | E295FMM1 |
| Brand | EDO |
| Size | 3.0 |
| Application | HMD VR AR |
| Resolution | 1080×1200 |
| Composition | OLED , AM-OLED |
| Brightness | |
| CR | 10000:1 |
| Colors | 16.7M |
| Backlight | self |
| Interface | MIPI |
| Manufacturer | EDO |
| Screen Size | 3.0 inch |
| Pixel Number | 1080(RGB)×1200 446PPI |
| Active Area(mm) | 50.11 × 55.68 (H×V) |
| Luminance | 300 cd/m² (Typ.) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥200) |
| Good View at | Symmetry |
| Color Depth | 16.7M 105% NTSC |
| Mass | 10±1g |
| Refresh Rate | 60Hz |
| Driver IC list | Built-in COG RM67295 |
| Signal Type | MIPI (4 data lanes) , 39 pins FPC |
| Voltage Supply | 1.8/3.3/4.6/-2.5/6.4V (Typ.)(VDDI/VCI/ELVDD/ELVSS/VSP) |
| Max. Ratings | Storage Temp.: -55 ~ 125 °C Operating Temp.: -40 ~ 85 °C |
| Model Name | E295FMM1 |
| Screen Type | OLED , AM-OLED |
| Arrangement | Sub-Pixel Rendering |
| Outline(mm) | 52.91 × 62.58 × 0.75 (H×V×D) |
| Contrast Ratio | 10000 : 1 (Min.) (TM) |
| Response | 2 (Max.)(Tr+Td) ms |
| Work Mode | - |
| Used for | HMD VR AR |
| Touchscreen | Without |
