| PartNumber | ECX331DB-6 |
| Brand | Sony |
| Size | 0.50 |
| Application | HMD VR AR |
| Resolution | 1024(RGB)×768, XGA, 2510PPI |
| Composition | Si-OLED, OLED |
| Brightness | 500 cd/m² (Typ.) |
| CR | 5000:1 |
| Colors | 16.7M |
| Backlight | self |
| Interface | Parallel |
| Panel Brand | Sony |
| Panel Model | ECX331DB-6 |
| Panel Size | 0.50" |
| Panel Type | Si-OLED, OLED |
| Pixel Format | RGB Delta |
| Display Area | 10.336(W)×7.8(H) mm |
| Bezel Opening | - |
| Outline Size | 17.8(W)×15.2(H) ×2.28(D) mm |
| Surface | - |
| Contrast Ratio | 5000:1 (Min.) (TM) |
| Viewing Angle | - |
| Display Mode | - |
| Best View on | Symmetry |
| Response Time | - |
| Display Colors | 16.7M 100% sRGB |
| Lamp Type | self |
| Frequency | - |
| Touch Screen | Without |
| Panel Weight | - |
| Signal Interface | Parallel RGB (1 ch, 8-bit) + SPI , 61 pins FPC |
| Input Voltage | 3.0/12.5/10.0/12.5V (Typ.)(VDD1/VDD2/VDD4/DS_H) |
| Environment | Operating Temp.: -10 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
