| PartNumber | ECX337AF |
| Brand | Sony |
| Size | 0.50 |
| Application | HMD VR AR |
| Resolution | 1280×960 |
| Composition | OLED, Si-OLED |
| Brightness | |
| CR | 10000:1 |
| Colors | 1.07B |
| Backlight | self |
| Interface | LVDS |
| Manufacturer | Sony |
| Model Name | ECX337AF |
| Screen Size | 0.50 inch |
| Screen Type | OLED, Si-OLED |
| Pixel Number | 1280(RGB)×960 (Quad-VGA) 3200PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 10.14 × 7.644 (H×V) |
| Outline(mm) | 17.8 × 15.2 × 2.28 (H×V×D) |
| Luminance | 1000 cd/m² (Max.) |
| Contrast Ratio | 10000 : 1 (Min.) (TM) |
| Viewing Angle | - |
| Response | - |
| Good View at | Symmetry |
| Work Mode | - |
| Color Depth | 1.07B 80% NTSC |
| Mass | - |
| Used for | HMD VR AR |
| Refresh Rate | 120Hz |
| Touchscreen | Without |
| Signal Type | LVDS , FPC 60 pins |
| Voltage Supply | 1.8/10V (Typ.)(VDD1/VDD2) |
| Max. Ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -10 ~ 70 °C |
