| PartNumber | ED078KC1 |
| Brand | E Ink |
| Size | 7.8 |
| Application | E-Book Reader |
| Resolution | 1404×1872, 300PPI |
| Composition | EPD , EPD |
| Brightness | - |
| CR | 16:1 |
| Colors | Grayscale |
| Backlight | No |
| Interface | Parallel |
| Panel Brand | E Ink |
| Panel Size | 7.8" |
| Display Area | 118.638(W)×158.184(H) mm |
| Outline Size | 127.6(W)×173.8(H) ×2.05(D) mm |
| Viewing Angle | - |
| Best View on | - |
| Display Colors | Grayscale |
| Frequency | 85Hz |
| Panel Weight | 36.9±5.0g |
| Signal Interface | Parallel Data (2ch, 8-bit) , 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 70 °C |
| Panel Model | ED078KC1 |
| Panel Type | EPD , EPD |
| Pixel Format | Rectangle |
| Bezel Opening | - |
| Surface | - |
| Contrast Ratio | 16:1 (Typ.) (RF) |
| Display Mode | - |
| Response Time | - |
| Lamp Type | No B/L |
| Touch Screen | Without |
