| PartNumber | EMA-101125 |
| Brand | eMagin |
| Size | 0.59 |
| Application | HMD VR AR |
| Resolution | 800×600 |
| Composition | OLED , Si-OLED |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | self |
| Interface | Parallel |
| Manufacturer | eMagin |
| Screen Size | 0.59 inch |
| Pixel Number | 800(RGB)×600 (SVGA) 1693PPI |
| Active Area(mm) | 12 × 9 (H×V) |
| Luminance | 150 cd/m² (Typ.) |
| Viewing Angle | - |
| Good View at | Symmetry |
| Color Depth | 16.7M 52% NTSC |
| Mass | 2.00g (Typ.) |
| Refresh Rate | 60Hz |
| Signal Type | Parallel RGB (1 ch, 8-bit) , 40 pins Connector |
| Voltage Supply | 1.8/5.0V (Typ.)(VDD1.8/VDD5) |
| Max. Ratings | Storage Temp.: -55 ~ 90 °C Operating Temp.: -45 ~ 70 °C |
| Model Name | EMA-101125 |
| Screen Type | OLED , Si-OLED |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 18 × 16 × 5.4 (H×V×D) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Response | - |
| Work Mode | - |
| Used for | HMD VR AR |
| Touchscreen | Without |
