| PartNumber | EMA-101162 |
| Brand | eMagin |
| Size | 0.59 |
| Application | HMD VR AR |
| Resolution | 800×600 |
| Composition | Si-OLED , OLED |
| Brightness | |
| CR | 1000:1 |
| Colors | Grayscale(G) |
| Backlight | self |
| Interface | |
| Diagonal Size | 0.59 inch |
| Pixel Format | 800(LCR)×600 [SVGA] 1693PPI |
| Active Area | 12(H)×9(V) mm |
| Luminance | 5000 cd/m² (Typ.) |
| View Direction | Symmetry |
| Viewing Angle | - |
| Support Color | Grayscale(G) 52% NTSC |
| Weight | 2.00g (Typ.) |
| Frame Rate | 60Hz |
| Model | EMA-101162 |
| Type | Si-OLED , OLED |
| Configuration | LCR Vertical Stripe |
| Outline Dim. | 18(H)×16(V) ×5.4(D) mm |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Response Time | - |
| Operating Mode | - |
| Light Source | self |
| Designed For | HMD VR AR |
| Touch Panel | Without |
