| PartNumber | EMA-101201 |
| Brand | eMagin |
| Size | 0.63 |
| Application | HMD VR AR |
| Resolution | 1280×1024 |
| Composition | Si-OLED, OLED |
| Brightness | |
| CR | 1000:1 |
| Colors | Grayscale |
| Backlight | self |
| Interface | LVDS |
| Model | EMA-101201 |
| Diagonal Size | 0.63 inch |
| Type | Si-OLED, OLED |
| Pixel Format | 1280(LCR)×1024 [SXGA] 2619PPI |
| Configuration | LCR Vertical Stripe |
| Active Area | 12.4(H)×9.945(V) mm |
| Outline Dim. | 19.5(H)×14.8(V) ×5.4(D) mm |
| Luminance | 900 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | - |
| Viewing Angle | - |
| Operating Mode | - |
| Support Color | Grayscale 52% NTSC |
| Light Source | self |
| Weight | 3.00g (Typ.) |
| Designed For | HMD VR AR |
| Frame Rate | - |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Power Supply | 5/1.8/-1.5V (Typ.)(VDC/VDD/VPG) |
| Environment | Operating Temperature: -45 ~ 70 °C ; Storage Temperature: -55 ~ 90 °C |
