| PartNumber | EMA-101204-01 |
| Brand | eMagin |
| Size | 0.63 |
| Application | HMD VR AR |
| Resolution | 1280(RGB)×1024, SXGA, 2619PPI |
| Composition | Si-OLED, OLED |
| Brightness | 700 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | self |
| Interface | LVDS |
| Panel Brand | eMagin |
| Panel Model | EMA-101204-01 |
| Panel Size | 0.63" |
| Panel Type | Si-OLED, OLED |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 12.4(W)×9.945(H) mm |
| Bezel Opening | - |
| Outline Size | 19.5(W)×14.8(H) ×5.4(D) mm |
| Surface | - |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | - |
| Display Mode | - |
| Best View on | Symmetry |
| Response Time | - |
| Display Colors | 16.7M 52% NTSC |
| Lamp Type | self |
| Frequency | - |
| Touch Screen | Without |
| Panel Weight | 3.00g (Max.) |
| Signal Interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Input Voltage | 5/1.8/-1.5V (Typ.)(VDC/VDD/VPG) |
| Environment | Operating Temp.: -45 ~ 70 °C ; Storage Temp.: -55 ~ 90 °C |
