| PartNumber | EMA-101402-01 |
| Brand | eMagin |
| Size | 0.77 |
| Application | HMD VR AR |
| Resolution | 1280×1024 |
| Composition | OLED, Si-OLED |
| Brightness | |
| CR | 1000:1 |
| Colors | Grayscale(G) |
| Backlight | self |
| Interface | Parallel |
| Manufacturer | eMagin |
| Model Name | EMA-101402-01 |
| Screen Size | 0.77 inch |
| Screen Type | OLED, Si-OLED |
| Pixel Number | 1280(LCR)×1024 (SXGA) 2116PPI |
| Arrangement | LCR Vertical Stripe |
| Active Area(mm) | 15.36 × 12.29 (H×V) |
| Outline(mm) | 22.9 × 16.4 (H×V×D) |
| Luminance | 5000 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Min.) (TM) |
| Viewing Angle | - |
| Response | - |
| Good View at | Symmetry |
| Work Mode | - |
| Color Depth | Grayscale(G) |
| Mass | 2.50g (Typ.) |
| Used for | HMD VR AR |
| Refresh Rate | 85Hz |
| Touchscreen | Without |
| Signal Type | Parallel RGB , Connector 50 pins |
| Voltage Supply | 2.5/5/-1.4/-2.0V (Typ.)(VDD/VAN/VCOM/VPG) |
| Max. Ratings | Storage Temp.: -55 ~ 90 °C Operating Temp.: -45 ~ 70 °C |
