| PartNumber | ET0320A5DM9 |
| Brand | EDT |
| Size | 3.2 |
| Application | MPH |
| Resolution | 240(RGB)×320 , QVGA |
| Composition | LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 450:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | CPU |
| Panel Brand | EDT |
| Panel Model | ET0320A5DM9 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 3.2 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 48.6×64.8 mm |
| Outline | 55.14×76.8×6 mm |
| Surface | |
| Contrast Ratio | 450:1 (Typ.) |
| Display Colors | 262K (6-bit) |
| Response Time | 5/15 (Typ.)(Tr/Td) |
| Viewing Angle | 63/70/65/72 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | 6S1PWLEDWithout Driver |
| Signal Interface | 8/9/16/18-bit 8080 parallel, 41 pins |
| Input Voltage | 3.3/3.3V (Typ.)(IOVCC/VCC) |
