| PartNumber | ET104S0M-N11 |
| Brand | BOE |
| Size | 10.4 |
| Application | Industrial |
| Resolution | 800×600 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 800:1 |
| Colors | 262K/16.2M |
| Backlight | WLED |
| Interface | LVDS |
| Diagonal Size | 10.4 inch |
| Pixel Format | 800(RGB)×600 [SVGA] 96PPI |
| Active Area | 211.2(H)×158.4(V) mm |
| Bezel Area | 215(H)×162(V) mm |
| Luminance | 350 cd/m² (Typ.) |
| View Direction | 12 o'clock |
| Viewing Angle | 80/80/65/75 (Typ.)(CR≥10) |
| Support Color | 262K/16.2M 55% NTSC |
| Weight | 288g (Typ.) |
| Frame Rate | 60Hz |
| Interface Type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| Model | ET104S0M-N11 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 236(H)×176.9(V) ×5.9(D) mm |
| Treatment | Antiglare (Haze 25%) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Response Time | 30 (Typ.)(Tr+Td) |
| Operating Mode | TN, Normally White, Transmissive |
| Light Source | WLED , 30K hours , W/O Driver |
| Designed For | Industrial |
| Touch Panel | Without |
