| PartNumber | EV101WUM-N20 |
| Brand | BOE |
| Size | 10.1 |
| Application | Medical Imaging |
| Resolution | 1920×1200 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 900:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Model | EV101WUM-N20 |
| Diagonal Size | 10.1 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1920(RGB)×1200 [WUXGA] 224PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 216.806(H)×135.504(V) mm |
| Outline Dim. | 229.45(H)×149.22(V) mm |
| Luminance | 600 cd/m² (Typ.) |
| Contrast Ratio | 900:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Operating Mode | ADS, Normally Black, Transmissive |
| Support Color | 16.7M 72% NTSC |
| Light Source | WLED , W/O Driver |
| Weight | - |
| Designed For | Medical Imaging |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 8-bit) , 45 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -25 ~ 80 °C |
