| PartNumber | EV121WXM-N12 |
| Brand | BOE |
| Size | 12.1 |
| Application | Medical Imaging |
| Resolution | 1280×800 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 1200:1 |
| Colors | 262K/16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Model | EV121WXM-N12 |
| Diagonal Size | 12.1 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1280(RGB)×800 [WXGA] 124PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 261.12(H)×163.2(V) mm |
| Outline Dim. | 277.7(H)×180.6(V) ×9.2(D) mm |
| Bezel Area | 264.12(H)×166.2(V) mm |
| Treatment | Antiglare (Haze 25%) |
| Luminance | 500 cd/m² (Typ.) |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Operating Mode | ADS, Normally Black, Transmissive |
| Support Color | 262K/16.7M 100% sRGB |
| Light Source | WLED [12S4P] , 50K hours , With LED Driver |
| Weight | TBD |
| Designed For | Medical Imaging |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
