| PartNumber | EV190E0M-N50 |
| Brand | BOE |
| Size | 19.0 |
| Application | Medical Imaging |
| Resolution | 1280(LCR)×1024, SXGA, 86PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 1300 cd/m² (Typ.) |
| CR | 1200:1 |
| Colors | Grayscale |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | BOE |
| Panel Model | EV190E0M-N50 |
| Panel Size | 19.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 374.784(W)×299.827(H) mm |
| Bezel Opening | 378.8(W)×303(H) mm |
| Outline Size | 396(W)×324(H) ×10.4(D) mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 1200:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | ADS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 14 (Typ.)(G to G) |
| Display Colors | Grayscale |
| Lamp Type | WLED , 50K hours , Without Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 1.69Kgs (Typ.) |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| G190EG02 V0 | AUO | 19.0 | 1280×1024 |
| G190ETN02.0 | AUO | 19.0 | 1280×1024 |
| HSD190MEN3-A03 | HannStar | 19.0 | 1280×1024 |
| LM190E09-TLD1 | LG Display | 19.0 | 1280×1024 |
| LTM190BT03 | Samsung | 19.0 | 1440×900 |
| M190EG02 V9 | AUO | 19.0 | 1280×1024 |
| M190PP01 V0 | AUO | 19.0 | 1440×900 |
| MT190AW01 V.C | Innolux | 19.0 | 1440×900 |
| NA19020-C961 | Fujitsu | 19.0 | 1280×1024 |
| TMS190WX1-05TB | Tianma | 19.0 | 1440×900 |
