| PartNumber | EW50722NCW |
| Brand | EDT |
| Size | 7.2 |
| Application | Industrial |
| Resolution | 640×480 |
| Composition | FFSTN-LCD, LCM |
| Brightness | |
| CR | 20:1 |
| Colors | Monochrome |
| Backlight | CCFL |
| Interface | Parallel |
| Model | EW50722NCW |
| Diagonal Size | 7.2 inch |
| Type | FFSTN-LCD, LCM |
| Pixel Format | 640×480 [VGA] 110PPI |
| Configuration | Rectangle |
| Active Area | 147.18(H)×110.38(V) mm |
| Outline Dim. | 205.5(H)×141(V) ×7(D) mm |
| Bezel Area | 153(H)×115.4(V) mm |
| Treatment | - |
| Luminance | 80 cd/m² (Typ.) |
| Contrast Ratio | 20:1 (Typ.) (TM) |
| View Direction | 6 o'clock |
| Response Time | 300/140 (Typ.)(Tr/Td) |
| Viewing Angle | 30/30/25/25 (Typ.)(CR≥10) |
| Operating Mode | STN, Black/White (Negative), Transmissive |
| Support Color | Monochrome |
| Light Source | CCFL [1 pcs] , 50K hours , W/O Driver |
| Weight | - |
| Designed For | Industrial |
| Frame Rate | 85Hz |
| Touch Panel | Without |
| Interface Type | Parallel Data (2ch, 4-bit) , 15 pins FPC |
| Power Supply | 3.3/5.0V (Typ.)(VDD) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 70 °C |
