| PartNumber | F080A35-602 |
| Brand | Innolux |
| Size | 8.0 |
| Application | Digital Photo Frame |
| Resolution | 1024(RGB)×768, XGA, 160PPI |
| Composition | a-Si TFT-LCD , CELL |
| Brightness | 0 cd/m² |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | No |
| Interface | |
| Panel Brand | Innolux |
| Panel Size | 8.0" |
| Display Area | 162.048(W)×121.536(H) mm |
| Outline Size | 171.124(W)×132.618(H) ×0.8(D) mm |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Glass Depth | 0.40+0.40 mm |
| Display Colors | 16.7M |
| Frequency | - |
| Driver IC | COG Suggest NT39212C+NT51008 |
| Panel Weight | - |
| Environment | Operating Temp.: -10 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| Panel Model | F080A35-602 |
| Panel Type | a-Si TFT-LCD , CELL |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | - |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Display Mode | AAS, Normally Black, Transmissive |
| Response Time | 25 (Typ.)(Tr+Td) |
| Transmissivity | 4.0% (Typ.) |
| Lamp Type | No B/L |
| Touch Screen | Without |
