| PartNumber | F101NWN7 R0 |
| Brand | IVO |
| Size | 10.1 |
| Application | Pad & Tablet |
| Resolution | 1920(RGB)×1200, WUXGA, 224PPI |
| Composition | a-Si TFT-LCD, CELL |
| Brightness | 0 cd/m² |
| CR | 800:1 |
| Colors | 60% |
| Backlight | No |
| Interface | |
| Panel Brand | IVO |
| Panel Model | F101NWN7 R0 |
| Panel Size | 10.1" |
| Panel Type | a-Si TFT-LCD, CELL |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 217.44(W)×135.9(H) mm |
| Bezel Opening | - |
| Outline Size | 225.5(W)×144.4(H) ×0.4(D) mm |
| Surface | - |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Display Mode | IPS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 65/45 (Max.)(Tr/Td) |
| Glass Depth | 0.20+0.20 mm |
| Transmissivity | 3.8% (Typ.)(with Polarizer) |
| Display Colors | 60% NTSC |
| Lamp Type | No B/L |
| Frequency | - |
| Touch Screen | Without |
| Panel Weight | 56.1g (Max.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
