| PartNumber | FDCC0802C-FLYYBH-91LE |
| Brand | Fordata |
| Size | 1.1 |
| Application | Instruments & Meters |
| Resolution | 8×27 |
| Composition | STN-LCD, LCM |
| Brightness | - |
| CR | 6:1 |
| Colors | Monochrome |
| Backlight | YG-LED |
| Interface | 8-bit |
| Panel Brand | Fordata |
| Panel Model | FDCC0802C-FLYYBH-91LE |
| Panel Size | 1.1" |
| Panel Type | STN-LCD, LCM |
| Display Format | 8 characters × 2 lines, 7PPI |
| Font Format | 5×8 dots |
| Character Size | 2.95×4.75(W×H) mm |
| Character Pitch | 3.35×5.15(W×H) mm |
| Display Area | 26.4(W)×9.9(H) mm |
| Bezel Opening | 30.4(W)×13.9(H) mm |
| Outline Size | 40(W)×35.4(H) ×13(D) mm |
| Surface | - |
| Contrast Ratio | 6:1 (Typ.) (TM) |
| Viewing Angle | - |
| Display Mode | STN, Yellow/Green (Positive), Transflective |
| Best View on | 6 o'clock |
| Response Time | 150/150 (Typ.)(Tr/Td) |
| Display Colors | Monochrome |
| Lamp Type | YG-LED , 9K hours , Without Driver |
| Frequency | - |
| Touch Screen | Without |
| Panel Weight | - |
| Signal Interface | 8-bit parallel , 16 pins Pad |
| Input Voltage | 3.0V (Typ.) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
