| PartNumber | FG050020DNCWBG01 |
| Brand | Data Image |
| Size | 5.0 |
| Application | Industrial |
| Resolution | 320(RGB)×234, 79PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 350:1 |
| Colors | 262K |
| Backlight | WLED |
| Interface | |
| Panel Brand | Data Image |
| Panel Size | 5.0" |
| Display Area | 102.72(W)×74.53(H) mm |
| Outline Size | 126.6(W)×92.4(H) mm |
| Viewing Angle | 60/60/40/60 (Typ.)(CR≥10) |
| Best View on | - |
| Display Colors | 262K |
| Frequency | 60Hz |
| Weight | 168g (Typ.) |
| Panel Model | FG050020DNCWBG01 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | 107(W)×78.9(H) mm |
| Surface | Antiglare |
| Contrast Ratio | 350:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 5/25 (Typ.)(Tr/Td) |
| Lamp Type | WLED , 20K hours , Without Driver |
| Touch Screen | Without |
