| PartNumber | G101STN01.5 |
| Brand | AUO |
| Size | 10.1 |
| Application | Industrial |
| Resolution | 1024×600 |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | |
| CR | 500:1 |
| Colors | 262K/16.7M |
| Backlight | WLED |
| Interface | Parallel |
| Diagonal Size | 10.1 inch |
| Pixel Format | 1024(RGB)×600 [WSVGA] 117PPI |
| Active Area | 222.72(H)×125.28(V) mm |
| Bezel Area | 226.43(H)×128.1(V) mm |
| Luminance | 350 cd/m² (Typ.) |
| View Direction | - |
| Viewing Angle | 70/70/60/60 (Typ.)(CR≥10) |
| Support Color | 262K/16.7M 45% NTSC |
| Weight | 340g (Max.) |
| Frame Rate | 60Hz |
| Interface Type | Parallel RGB (1 ch, 6/8-bit) , 50 pins FPC |
| Power Supply | 3.3/10/18/-8V (Typ.)(VDD/AVDD/VGH/VGL) |
| Environment | Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| Model | G101STN01.5 |
| Type | a-Si TFT-LCD , LCM |
| Configuration | RGB Vertical Stripe |
| Outline Dim. | 235(H)×143(V) ×5.5(D) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Response Time | 7/9 (Typ.)(Tr/Td) |
| Operating Mode | TN, Normally White, Transmissive |
| Light Source | WLED , 15K hours , W/O Driver |
| Designed For | Industrial |
| Touch Panel | Without |
