| PartNumber | G104AGE-L02 |
| Brand | Innolux |
| Size | 10.4 |
| Application | IA |
| Resolution | 800(RGB)×600 , SVGA |
| Composition | LCM |
| Brightness | 400 cd/m² (Typ.) |
| CR | 700:1 |
| Colors | 262K/16.2M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | INNOLUX |
| Panel Model | G104AGE-L02 |
| Panel Type | a-Si TFT-LCD , LCM |
| Panel Size | 10.4 inch |
| Display Mode | TN, Normally White, Transmissive |
| Active Area | 211.2×158.4 mm |
| Outline | 243×184 mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 700:1 (Typ.) |
| Display Colors | 262K/16.2M (6-bit / 6-bit + FRC), CIE193153% |
| Response Time | 5/11 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/70/70 (Typ.)(CR≥10)(L/R/U/D) |
| Frequency | 60Hz |
| Lamp Type | WLEDEmbedded (LED Driver) |
| Signal Interface | LVDS (1 ch, 6/8-bit), 20 pins |
| Input Voltage | 3.3V (Typ.) |
| AA104VC04 | Mitsubishi | 10.4 | 640×480 |
| DLC1040ABG-2 | Other | 10.4 | 800×600 |
| G104AGE-L02 | Innolux | 10.4 | 800×600 |
| G104S1-L01 | Innolux | 10.4 | 800×600 |
| G104X1-L04 | Innolux | 10.4 | 1024×768 |
| G104XVN01.0 | AUO | 10.4 | 1024×768 |
| NL10276BC20-18 | NLT | 10.4 | 1024×768 |
| NL6448BC33-70D | NLT | 10.4 | 640×480 |
| NL8060BC26-11 | NLT | 10.4 | 800×600 |
| NL8060BC26-27 | NLT | 10.4 | 800×600 |
| AA121XJ02 | Mitsubishi | 12.1 | 1024×768 |
| AM-320240N1TMQW-T30H-D(R) | AMPIRE | 5.7 | 320×240 |
| AM-800480LTMQW-W0H | AMPIRE | 5.0 | 800×480 |
| AT056TN52 | Innolux | 5.6 | 640×480 |
| G150XTN05.0 | AUO | 15.0 | 1024×768 |
| G150XVN01.0 | AUO | 15.0 | 1024×768 |
| LLB121ST01 | Samsung | 12.1 | 800×600 |
| LM270WF5-SLM1 | LG Display | 27.0 | 1920×1080 |
| LTM12C275A | TOSHIBA | 12.1 | 800×600 |
| TM121SV-A01 | SANYO | 12.1 | 800×600 |
