| PartNumber | G104STN01.4 |
| Brand | AUO |
| Size | 10.4 |
| Application | Industrial |
| Resolution | 800×600 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 700:1 |
| Colors | 262K/16.2M |
| Backlight | WLED |
| Interface | LVDS |
| Model | G104STN01.4 |
| Diagonal Size | 10.4 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 800(RGB)×600 [SVGA] 96PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 211.2(H)×158.4(V) mm |
| Outline Dim. | - |
| Luminance | - |
| Contrast Ratio | 700:1 (Typ.) (TM) |
| View Direction | - |
| Response Time | - |
| Viewing Angle | 80/80/60/70 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K/16.2M |
| Light Source | WLED |
| Weight | - |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 6/8-bit) |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
