| PartNumber | G133XTN01.0 |
| Brand | AUO |
| Size | 13.3 |
| Application | Industrial |
| Resolution | 1366(RGB)×768, WXGA, 118PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 300 cd/m² (Typ.) |
| CR | 400:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | AUO |
| Panel Size | 13.3" |
| Display Area | 293.42(W)×164.97(H) mm |
| Outline Size | 306.3(W)×197.2(H) mm |
| Viewing Angle | 70/70/50/60 (Typ.)(CR≥10) |
| Best View on | - |
| Display Colors | 16.7M 45% NTSC |
| Frequency | 60Hz |
| Panel Weight | 255g (Max.) |
| Signal Interface | LVDS (1 ch, 8-bit) , 40 pins Connector |
| Input Voltage | 3.3V (Typ.) |
| Environment | Operating Temp.: -20 ~ 60 °C ; Storage Temp.: -30 ~ 70 °C |
| Panel Model | G133XTN01.0 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 400:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 5.7/2.3 (Typ.)(Tr/Td) |
| Lamp Type | WLED , 20K hours , With LED Driver |
| Touch Screen | Without |
