| PartNumber | G150XNE-L02 |
| Brand | Innolux |
| Size | 15.0 |
| Application | Industrial Gaming |
| Resolution | 1024×768 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 2500:1 |
| Colors | 262K/16.2M |
| Backlight | WLED |
| Interface | LVDS |
| Model | G150XNE-L02 |
| Diagonal Size | 15.0 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1024(RGB)×768 [XGA] 85PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 304.128(H)×228.096(V) mm |
| Outline Dim. | 326.5(H)×253.5(V) ×9.6(D) mm |
| Bezel Area | 307.4(H)×231.3(V) mm |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 2500:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 13/5 (Typ.)(Tr/Td) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) |
| Operating Mode | NPVA, Normally Black, Transmissive |
| Support Color | 262K/16.2M 72% NTSC |
| Light Source | WLED , 70K hours , With LED Driver |
| Weight | 0.97/1.00Kgs (Typ./Max.) |
| Designed For | Industrial Gaming |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -30 ~ 70 °C ; Storage Temperature: -40 ~ 70 °C |
