| PartNumber | G150XTN03.6 |
| Brand | AUO |
| Size | 15.0 |
| Application | Industrial |
| Resolution | 1024×768 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 500:1 |
| Colors | 262K/16.2M |
| Backlight | WLED , 50K hours , With LED Driver |
| Interface | LVDS |
| Manufacturer | AUO |
| Screen Size | 15.0 inch |
| Pixel Number | 1024(RGB)×768 (XGA) 85PPI |
| Active Area(mm) | 304.128 × 228.096 (H×V) |
| Bezel Area(mm) | 313.55 × 237.25 (H×V) |
| Luminance | 250 cd/m² (Typ.) |
| Viewing Angle | 45/45/20/40 (Typ.)(CR≥10) |
| Good View at | - |
| Color Depth | 262K/16.2M 60% NTSC |
| Mass | 1.10Kgs (Max.) |
| Refresh Rate | 60Hz |
| Signal Type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Voltage Supply | 3.3V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 65 °C |
| Model Name | G150XTN03.6 |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 326.5 × 253.5 × 10 (H×V×D) |
| Treatment | Antiglare, Hard coating (3H) |
| Contrast Ratio | 500 : 1 (Typ.) (TM) |
| Response | 5.7/2.3 (Typ.)(Tr/Td) ms |
| Work Mode | TN, Normally White, Transmissive |
| Used for | Industrial |
| Touchscreen | Without |
