| PartNumber | G150XTN06.9 |
| Brand | AUO |
| Size | 15.0 |
| Application | Industrial Outdoor H |
| Resolution | 1024×768 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 800:1 |
| Colors | 262K/16.2M |
| Backlight | WLED |
| Interface | LVDS |
| Model | G150XTN06.9 |
| Diagonal Size | 15.0 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1024(RGB)×768 [XGA] 85PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 304.128(H)×228.096(V) mm |
| Outline Dim. | 326.5(H)×253.5(V) ×10(D) mm |
| Bezel Area | 311.9(H)×236.85(V) mm |
| Treatment | Antiglare |
| Luminance | 1600 cd/m² (Typ.) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| View Direction | - |
| Response Time | 5.7/2.3 (Typ.)(Tr/Td) |
| Viewing Angle | 80/80/70/80 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 262K/16.2M 60% NTSC |
| Light Source | WLED , 50K hours , With LED Driver |
| Weight | 1.00Kgs (Max.) |
| Designed For | Industrial Outdoor High Brightness |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -30 ~ 70 °C ; Storage Temperature: -30 ~ 70 °C |
