| PartNumber | G156HAB02.1 |
| Brand | AUO |
| Size | 15.6 |
| Application | Industrial |
| Resolution | 1920×1080 |
| Composition | a-Si TFT-LCD, Assemb |
| Brightness | |
| CR | 800:1 |
| Colors | 16.2M |
| Backlight | WLED |
| Interface | |
| Model | G156HAB02.1 |
| Diagonal Size | 15.6 inch |
| Type | a-Si TFT-LCD, Assembly |
| Pixel Format | 1920(RGB)×1080 [FHD] 141PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 344.16(H)×193.59(V) mm |
| Outline Dim. | - |
| Bezel Area | - |
| Treatment | Hard coating (5H) |
| Luminance | - |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 25 (Typ.)(Tr+Td) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Operating Mode | AHVA, Normally Black, Transmissive |
| Support Color | 16.2M |
| Light Source | WLED , 50K hours , With LED Driver |
| Weight | - |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | On-Cell Touch |
| Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
