| PartNumber | G156XTN01.0 |
| Brand | AUO |
| Size | 15.6 |
| Application | Industrial |
| Resolution | 1366×768 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Model | G156XTN01.0 |
| Diagonal Size | 15.6 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1366(RGB)×768 [WXGA] 100PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 344.232(H)×193.536(V) mm |
| Outline Dim. | 363.8(H)×215.9(V) ×9.6(D) mm |
| Bezel Area | 350.4(H)×196.94(V) mm |
| Treatment | Antiglare, Hard coating (3H), Reflection 4.3% (Typ.) |
| Luminance | 400 cd/m² (Typ.) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| View Direction | 6 o'clock |
| Response Time | 10 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/50/80 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 16.7M 62% NTSC |
| Light Source | WLED , 50K hours , With LED Driver |
| Weight | 860g (Typ.) |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Power Supply | 3.3V (Typ.) |
| Environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
