| PartNumber | G156XTT03.0 |
| Brand | AUO |
| Size | 15.6 |
| Application | Industrial |
| Resolution | 1366×768 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 500:1 |
| Colors | 16.2M |
| Backlight | WLED |
| Interface | LVDS |
| Model | G156XTT03.0 |
| Diagonal Size | 15.6 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1366(RGB)×768 [WXGA] 100PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 344.232(H)×193.536(V) mm |
| Outline Dim. | - |
| Bezel Area | - |
| Treatment | Hard coating (7H) |
| Luminance | - |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| View Direction | - |
| Response Time | 6/2 (Typ.)(Tr/Td); 8 (Typ.)(G to G) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Operating Mode | TN, Normally White, Transmissive |
| Support Color | 16.2M |
| Light Source | WLED , 50K hours , With LED Driver |
| Weight | - |
| Designed For | Industrial |
| Frame Rate | 60Hz |
| Touch Panel | PCAP |
| Interface Type | LVDS (1 ch, 8-bit) , 30 pins Connector |
| Power Supply | 5.0V (Typ.) |
