| PartNumber | G156XW01 V4 |
| Brand | AUO |
| Size | 15.6 |
| Application | Industrial |
| Resolution | 1366(RGB)×768, WXGA, 100PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 500 cd/m² (Typ.) |
| CR | 500:1 |
| Colors | 16.2M |
| Backlight | WLED |
| Interface | |
| Panel Brand | AUO |
| Panel Size | 15.6" |
| Display Area | 344.232(W)×193.536(H) mm |
| Outline Size | 363.8(W)×215.9(H) mm |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Best View on | - |
| Display Colors | 16.2M 62% NTSC |
| Frequency | 60Hz |
| Weight | 860±40g |
| Panel Model | G156XW01 V4 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | 347.54(W)×196.83(H) mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 500:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | 6/2 (Typ.)(Tr/Td) |
| Lamp Type | WLED , 50K hours , With LED Driver |
| Touch Screen | Without |
