| PartNumber | G170HAN01.0 |
| Brand | AUO |
| Size | 17.0 |
| Application | Industrial |
| Resolution | 1920(RGB)×1920, 159PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 600 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 9S6P |
| Interface | |
| Panel Brand | AUO |
| Panel Size | 17.0" |
| Display Area | 305.28(W)×305.28(H) mm |
| Outline Size | 325.01(W)×319.33(H) ×12.2(D) mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 72% NTSC |
| Frequency | 60Hz |
| Weight | 1.20Kgs (Max.) |
| Panel Model | G170HAN01.0 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Display Mode | AHVA, Normally Black, Transmissive |
| Response Time | 13/12 (Typ.)(Tr/Td) |
| Lamp Type | 9S6P WLED , 50K hours , With LED Driver |
| Touch Screen | Without |
