| PartNumber | G190EAN01.3 |
| Brand | AUO |
| Size | 19.0 |
| Application | Industrial Medical I |
| Resolution | 1280×1024 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED , 50K hours , With LED Driver |
| Interface | LVDS |
| Manufacturer | AUO |
| Model Name | G190EAN01.3 |
| Screen Size | 19.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 1280(RGB)×1024 (SXGA) 86PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 376.32 × 301.056 (H×V) |
| Outline(mm) | 396 × 324 × 15.8 (H×V×D) |
| Bezel Area(mm) | 380.32 × 305.06 (H×V) |
| Treatment | Antiglare |
| Luminance | 330 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 13/12 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | AHVA, Normally Black, Transmissive |
| Color Depth | 16.7M 72% NTSC |
| Mass | 1.70±0.15Kgs |
| Used for | Industrial Medical Imaging |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit) , Connector 30 pins |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| G190EAN01.0 | AUO | 19.0 | 1280×1024 |
| G190EG01 V0 | AUO | 19.0 | 1280×1024 |
| G190EG01 V1 | AUO | 19.0 | 1280×1024 |
| G190EG01 V2 | AUO | 19.0 | 1280×1024 |
| G190EG02 V0 | AUO | 19.0 | 1280×1024 |
| G190EG02 V1 | AUO | 19.0 | 1280×1024 |
| G190ETN01.0 | AUO | 19.0 | 1280×1024 |
| G190ETN01.2 | AUO | 19.0 | 1280×1024 |
| G190ETN01.4 | AUO | 19.0 | 1280×1024 |
| G190ETN02.0 | AUO | 19.0 | 1280×1024 |
