| PartNumber | G190EAN01.6 |
| Brand | AUO |
| Size | 19.0 |
| Application | Industrial Medical I |
| Resolution | 1280×1024 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | LVDS |
| Model | G190EAN01.6 |
| Diagonal Size | 19.0 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 1280(RGB)×1024 [SXGA] 86PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 376.32(H)×301.056(V) mm |
| Outline Dim. | 396(H)×324(V) ×15.8(D) mm |
| Bezel Area | 380.32(H)×305.06(V) mm |
| Treatment | Antiglare |
| Luminance | 1000 cd/m² (Typ.) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 13/12 (Typ.)(Tr/Td) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Operating Mode | AHVA, Normally Black, Transmissive |
| Support Color | 16.7M 72% NTSC |
| Light Source | WLED , 50K hours , With LED Driver |
| Weight | 1.70±0.15Kgs |
| Designed For | Industrial Medical Imaging Outdoor High Brightness |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Interface Type | LVDS (2 ch, 8-bit) |
| Power Supply | 5.0V (Typ.) |
| Environment | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
