| PartNumber | G190EG02 V104 |
| Brand | AUO |
| Size | 19.0 |
| Application | Industrial Medical I |
| Resolution | 1280×1024 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 2000:1 |
| Colors | 16.7M |
| Backlight | WLED , 50K hours , With LED Driver |
| Interface | LVDS |
| Manufacturer | AUO |
| Screen Size | 19.0 inch |
| Pixel Number | 1280(RGB)×1024 (SXGA) 86PPI |
| Active Area(mm) | 376.32 × 301.056 (H×V) |
| Bezel Area(mm) | 380.32 × 305.06 (H×V) |
| Luminance | 350 cd/m² (Typ.) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Good View at | Symmetry |
| Color Depth | 16.7M 70% NTSC |
| Mass | 1.74Kgs (Typ.) |
| Refresh Rate | 60Hz |
| Signal Type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 70 °C Operating Temp.: -15 ~ 70 °C |
| Model Name | G190EG02 V104 |
| Screen Type | LCM , a-Si TFT-LCD |
| Arrangement | RGB Vertical Stripe |
| Outline(mm) | 396 × 324 × 15.8 (H×V×D) |
| Treatment | Antiglare |
| Contrast Ratio | 2000 : 1 (Typ.) (TM) |
| Response | 15/5 (Typ.)(Tr/Td) ms |
| Work Mode | MVA, Normally Black, Transmissive |
| Used for | Industrial Medical Imaging |
| Touchscreen | Without |
