| PartNumber | G190ETN01.8 |
| Brand | AUO |
| Size | 19.0 |
| Application | Industrial Outdoor H |
| Resolution | 1280×1024 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED , 50K hours , No Driver |
| Interface | |
| Manufacturer | AUO |
| Model Name | G190ETN01.8 |
| Screen Size | 19.0 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 1280(RGB)×1024 (SXGA) 86PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 376.32 × 301.056 (H×V) |
| Outline(mm) | 396 × 324 (H×V×D) |
| Bezel Area(mm) | 379.72 × 304.46 (H×V) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 800 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) |
| Response | 7/3 (Typ.)(Tr/Td) ms |
| Good View at | - |
| Work Mode | TN, Normally White, Transmissive |
| Color Depth | 16.7M 70% NTSC |
| Mass | 1.80Kgs (Typ.) |
| Used for | Industrial Outdoor High Brightness |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Storage Temp.: -30 ~ 70 °C Operating Temp.: -30 ~ 70 °C |
