| PartNumber | G215HAN01.4 |
| Brand | AUO |
| Size | 21.5 |
| Application | Industrial Gaming |
| Resolution | 1920×1080 |
| Composition | LCM, a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED , No Driver |
| Interface | LVDS |
| Manufacturer | AUO |
| Model Name | G215HAN01.4 |
| Screen Size | 21.5 inch |
| Screen Type | LCM, a-Si TFT-LCD |
| Pixel Number | 1920(RGB)×1080 (FHD) 102PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 476.064 × 267.786 (H×V) |
| Outline(mm) | 497.6 × 292.2 × 11 (H×V×D) |
| Bezel Area(mm) | 479.8 × 271.3 (H×V) |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | - |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 12/10 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | AHVA, Normally Black, Transmissive |
| Color Depth | 16.7M |
| Mass | - |
| Used for | Industrial Gaming |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (2 ch, 8-bit) , Connector 30 pins |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
