| PartNumber | G229HAN01.0 |
| Brand | AUO |
| Size | 22.9 |
| Application | Industrial Stretched Bar LCD |
| Resolution | 1920(RGB)×165, 84PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | 500 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Panel Brand | AUO |
| Panel Size | 22.9" |
| Display Area | 578.88(W)×49.7475(H) mm |
| Outline Size | 587.08(W)×62.05(H) ×10.71(D) mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Best View on | Symmetry |
| Display Colors | 16.7M 72% NTSC |
| Frequency | 60Hz |
| Weight | 460g (Typ.) |
| Panel Model | G229HAN01.0 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | 580.88(W)×51.75(H) mm |
| Surface | Antiglare, Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Display Mode | AHVA, Normally Black, Transmissive |
| Response Time | 13/12 (Typ.)(Tr/Td) |
| Lamp Type | WLED , 70K hours , With LED Driver |
| Touch Screen | Without |
