| PartNumber | G270HAN01.0 |
| Brand | AUO |
| Size | 27.0 |
| Application | Industrial Outdoor High Brightness |
| Resolution | 1920(RGB)×1080, FHD, 81PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 1000 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 1.07B |
| Backlight | WLED |
| Interface | LVDS |
| Panel Brand | AUO |
| Panel Model | G270HAN01.0 |
| Panel Size | 27.0" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 597.888(W)×336.312(H) mm |
| Bezel Opening | 602(W)×340.4(H) mm |
| Outline Size | 630(W)×368.2(H) ×23.4(D) mm |
| Surface | Antiglare |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Display Mode | AHVA, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 14 (Typ.)(Tr+Td) |
| Display Colors | 1.07B 87% NTSC |
| Lamp Type | WLED , 50K hours , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 3.40Kgs (Typ.) |
| Signal Interface | LVDS , 51 pins Connector |
| Input Voltage | 12.0V (Typ.) |
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| HR270WU1-200 | BOE | 27.0 | 1920×1080 |
| LM270WF1-TLA1 | LG Display | 27.0 | 1920×1080 |
| LM270WF7-SSA1 | LG Display | 27.0 | 1920×1080 |
| LM270WF7-SSB1 | LG Display | 27.0 | 1920×1080 |
| LM270WQ1-SDE3 | LG Display | 27.0 | 2560×1440 |
| LM270WR2-SPA1 | LG Display | 27.0 | 3840×2160 |
| M270DTN01.0 | AUO | 27.0 | 2560×1440 |
| M270DTN01.1 | AUO | 27.0 | 2560×1440 |
| M270HGE-L20 | Innolux | 27.0 | 1920×1080 |
| M270QAN01.1 | AUO | 27.0 | 3840×2160 |
