| PartNumber | G270QAN02.0 |
| Brand | AUO |
| Size | 27.0 |
| Application | Industrial |
| Resolution | 2560×1440 |
| Composition | LCM , a-Si TFT-LCD |
| Brightness | |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 4 strings WLED , 30K hours , No Driver |
| Interface | LVDS |
| Manufacturer | AUO |
| Model Name | G270QAN02.0 |
| Screen Size | 27.0 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 2560(RGB)×1440 (Quad-HD) 108PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 596.74 × 335.66 (H×V) |
| Outline(mm) | 606.44 × 355.56 × 15.03 (H×V×D) |
| Bezel Area(mm) | - |
| Treatment | Antiglare, Hard coating (3H) |
| Luminance | 350 cd/m² (Typ.) |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) |
| Response | 8/8 (Typ.)(Tr/Td) ms |
| Good View at | Symmetry |
| Work Mode | AHVA, Normally Black, Transmissive |
| Color Depth | 16.7M 99% sRGB |
| Mass | 3.50Kgs (Typ.) |
| Used for | Industrial |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (4 ch, 8-bit) , 70 pins Connector |
| Voltage Supply | 5.0V (Typ.) |
| Max. Ratings | Storage Temp.: -20 ~ 55 °C Operating Temp.: 0 ~ 50 °C |
| LM270WQ1-SDB3 | LG Display | 27.0 | 2560×1440 |
| LM270WQ1-SDE3 | LG Display | 27.0 | 2560×1440 |
| LM270WQ1-SLC2 | LG Display | 27.0 | 2560×1440 |
| LTM270DL04 | Samsung | 27.0 | 2560×1440 |
| LTM270HT03 | Samsung | 27.0 | 1920×1080 |
| LTM270RL01 | Samsung | 27.0 | 5120×2880 |
| M270DTN01.0 | AUO | 27.0 | 2560×1440 |
| M270HGE-L10 | Innolux | 27.0 | 1920×1080 |
| M270HW02 V3 | AUO | 27.0 | 1920×1080 |
| M270QAN01.1 | AUO | 27.0 | 3840×2160 |
