| PartNumber | GV185FHM-N10-DM30 |
| Brand | BOE |
| Size | 18.5 |
| Application | Industrial |
| Resolution | 1920(RGB)×1080, FHD, 119PPI |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | 350 cd/m² (Typ.) |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | 11S4P |
| Interface | LVDS |
| Panel Brand | BOE |
| Panel Model | GV185FHM-N10-DM30 |
| Panel Size | 18.5" |
| Panel Type | a-Si TFT-LCD, LCM |
| Pixel Format | RGB Vertical Stripe |
| Display Area | 408.96(W)×230.04(H) mm |
| Bezel Opening | 410.96(W)×232.04(H) mm |
| Outline Size | 430.4(W)×254.6(H) ×12.5(D) mm |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Display Mode | ADS, Normally Black, Transmissive |
| Best View on | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Display Colors | 16.7M 70% NTSC |
| Lamp Type | 11S4P WLED , With LED Driver |
| Frequency | 60Hz |
| Touch Screen | Without |
| Panel Weight | 1.80Kgs (Typ.) |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector |
| Input Voltage | 5.0V (Typ.) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
