| PartNumber | H466TAN01.1 |
| Brand | AUO |
| Size | 4.7 |
| Application | MPH |
| Resolution | 720(RGB)×1280 , WXGA |
| Composition | CELL |
| Brightness | 0 |
| CR | 1000:1 |
| Colors | 16.7M |
| Backlight | No B/L |
| Interface | |
| Panel Brand | AUO |
| Panel Model | H466TAN01.1 |
| Panel Type | LTPS TFT-LCD , CELL |
| Panel Size | 4.7 inch |
| Display Mode | AHVA, Normally Black, Transmissive |
| Active Area | 58.104×103.296 mm |
| Outline | 60.9×111.87 mm |
| Surface | Hard coating |
| Glass Depth | 0.17+0.17 mm |
| Transmissivity | 3.9% (Typ.)(with Polarizer) |
| Contrast Ratio | 1000:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193166% |
| Response Time | 35 (Max.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| Driver IC | COG Built-in NT35590 |
