| PartNumber | H495TAN01.1 |
| Brand | AUO |
| Size | 5.0 |
| Application | MPH |
| Resolution | 720(RGB)×1280 , WXGA |
| Composition | CELL |
| Brightness | 0 |
| CR | 900:1 |
| Colors | 16.7M |
| Backlight | No B/L |
| Interface | |
| Panel Brand | AUO |
| Panel Model | H495TAN01.1 |
| Panel Type | a-Si TFT-LCD , CELL |
| Panel Size | 5.0 inch |
| Display Mode | AHVA, Normally Black, Transmissive |
| Active Area | 61.688×109.632 mm |
| Outline | 63.67×115.85×0.3 mm |
| Surface | |
| Glass Depth | 0.15+0.15 mm |
| Transmissivity | 3.26% (Typ.)(with Polarizer) |
| Contrast Ratio | 900:1 (Typ.) |
| Display Colors | 16.7M (8-bit), CIE193194% |
| Response Time | 35 (Max.)(Tr+Td) |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| Driver IC | COG Suggest HX8394-D21, N35521-DPAU, N35521S-DP8AU, OTM1284A-C6, OTM1287A-C8, R61318, RM68200 |
