| PartNumber | H546DLK01.0 |
| Brand | AUO |
| Size | 5.5 |
| Application | Mobile Phone |
| Resolution | 1080(RGB)×1920, FHD, 403PPI |
| Composition | AM-OLED , OLED |
| Brightness | 350 cd/m² (Typ.) |
| CR | 10000:1 |
| Colors | 16.7M |
| Backlight | self |
| Interface | MIPI |
| Panel Brand | AUO |
| Panel Size | 5.5" |
| Display Area | 68.04(W)×120.96(H) mm |
| Outline Size | 70.84(W)×128.01(H) ×0.92(D) mm |
| Viewing Angle | 80/80/80/80 (Min.)(CR≥1600) |
| Best View on | Symmetry |
| Display Colors | 16.7M 100% NTSC |
| Frequency | 100Hz |
| Driver IC | COG Built-in RM69071 |
| Panel Weight | - |
| Signal Interface | MIPI (4 data lanes) |
| Input Voltage | 1.8/3.1/5.8/4.6/-2.9V (Typ.)(IOVCC/VCI/AVDD/OVDD/OVSS) |
| Environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| Panel Model | H546DLK01.0 |
| Panel Type | AM-OLED , OLED |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Surface | Hard coating (3H) |
| Contrast Ratio | 10000:1 (Min.) (TM) |
| Display Mode | - |
| Response Time | - |
| Lamp Type | self |
| Touch Screen | Embeded Touch |
