| PartNumber | HSD070IFW1-B10 |
| Brand | HannStar |
| Size | 7.0 |
| Application | Automotive Display |
| Resolution | 1024(RGB)×600, WSVGA, 170PPI |
| Composition | a-Si TFT-LCD , LCM |
| Brightness | - |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Panel Brand | HannStar |
| Panel Size | 7.0" |
| Display Area | 153.6(W)×86.64(H) mm |
| Viewing Angle | - |
| Best View on | - |
| Display Colors | 16.7M |
| Frequency | - |
| Weight | - |
| Panel Model | HSD070IFW1-B10 |
| Panel Type | a-Si TFT-LCD , LCM |
| Pixel Format | RGB Vertical Stripe |
| Bezel Opening | - |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| Display Mode | TN, Normally White, Transmissive |
| Response Time | - |
| Lamp Type | WLED |
| Touch Screen | Without |
