| PartNumber | HSD080PWW2-B01 |
| Brand | HannStar |
| Size | 8.0 |
| Application | Pad & Tablet Ind |
| Resolution | 800×1280 |
| Composition | a-Si TFT-LCD, LCM |
| Brightness | |
| CR | 800:1 |
| Colors | 16.7M |
| Backlight | WLED |
| Interface | |
| Model | HSD080PWW2-B01 |
| Diagonal Size | 8.0 inch |
| Type | a-Si TFT-LCD, LCM |
| Pixel Format | 800(RGB)×1280 [WXGA] 188PPI |
| Configuration | RGB Vertical Stripe |
| Active Area | 107.64(H)×172.224(V) mm |
| Outline Dim. | 114.8(H)×184.7(V) ×3.71(D) mm |
| Bezel Area | - |
| Treatment | Hard coating (3H) |
| Luminance | 450 cd/m² (Typ.) |
| Contrast Ratio | 800:1 (Typ.) (TM) |
| View Direction | Symmetry |
| Response Time | 30 (Typ.)(Tr+Td) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) |
| Operating Mode | IPS Pro, Normally Black, Transmissive |
| Support Color | 16.7M 60% NTSC |
| Light Source | WLED [7S3P] , 15K hours , W/O Driver |
| Weight | 100g (Typ.) |
| Designed For | Pad & Tablet Industrial |
| Frame Rate | 60Hz |
| Touch Panel | Without |
| Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -30 ~ 65 °C |
